FM08-441
Category: Full-motion TV Wall Mount
Brief Specifications: for most 32″ to 55″ TVs, 35kg weight capacity, Max VESA 400×400
Color: Black only
Specifications:
| Product Category | Full-motion TV Wall Mount |
| Rank | Standard |
| Material | Steel, Plastic |
| Surface Finish: | Powder Coating |
| Color: | Fine Texture Black |
| Fit Screen Size: | 32″-55″ |
| Fit Curved TV: | Yes |
| Mounting Hole Pattern: | Universal |
| Weight Capacity: | 35kg |
| VESA Compatible: | 400×400, 300×300,200×200, 200×100, 100X100 |
| Max. Mounting Hole: | 400×400 |
| Strength Tested: | 3 Times Approved |
| Profile: | 45-255mm (1.77-10″) |
| Tilt Range: | +5°~-8° |
| Swivel Range: | +90°~-90 |
| Screen Level: | +3°~-3° |
| Screen Freely Tilting: | Yes |
| Installation: | Solid wall, stud |
| Panel Type: | Detachable Panel |
| Accessory Kit Package: | Compartment Polybag |
Resources:
Manual-FM08-441
