FM09-686
Category: Full-motion TV Wall Mount
Brief Specifications: for most 43″ to 100″ TVs, 80kg weight capacity, Max VESA 800×600
Color: Black only
Specifications:
| Product Category | Full-motion TV Wall Mount |
| Rank | Standard |
| Material | Steel, Plastic |
| Surface Finish: | Powder Coating |
| Color: | Fine Texture Black |
| Fit Screen Size: | 43″-100″ |
| Fit Curved TV: | Yes |
| Mounting Hole Pattern: | Universal |
| Weight Capacity: | 80kg |
| VESA Compatible: | 800×600, 600×400, 400×400, 400×200, 300×300, 300×200, 200X200 |
| Max. Mounting Hole: | 800×600 |
| Strength Tested: | 3 Times Approved |
| Profile: | 50-500mm (2-20″) |
| Tilt Range: | +5°~-15° |
| Swivel Range: | -60°~+60° |
| Screen Level: | -3°~+3° |
| Screen Freely Tilting: | Yes |
| Installation: | Solid wall, Double Stud, Double Stud |
| Panel Type: | Detachable Panel |
| Accessory Kit Package: | Compartment Polybag |
Resources:
Manual-FM09-686
